Three-ports in situ setup for static NMR/MRI probes

• Magnet shielding plate for wide-bore magnet
• Three non-magnetic double-shielded cables with eyelet soldered to one side (connection to the in situ cell) and SMA adapter on the side that connects to the shielding plate. The SMA adapter has rotating end; i.e. the cable will not twist when attaching it to the SMA ports of the shielding plate.
• Note, cable length will be customised depending on the dimensions of the magnet/bore
• Three SLP-2.5+ filters
• Three SLP-5+ filters
• Three RG316 in situ cables (5 m each) to connect the shielding plate to the electrochemical cycler/potentiostat (SMA socket / SMA plug)
• Three SMA—banana plug adapters suitable for Biologic SP-150e and similar devices

Three-way in situ cell adapter

• In situ cell adapter to clip, solder, or through-hole connections of in situ cells (plastic cell capsule and other designs)
• Attached to three non-magnetic double-shielded cables with SMA adapters to the shielding plate
• Note, length will be customised depending on the dimensions of the magnet/bore
